Filter
| Filter stages | 1 |
| Filter method | Cleanable filter |
| Filter surface | 72.12 sq ft (6.7 m²) |
| Type of filter | Filter cartridge |
| Filter material | KemTex® ePTFE membrane |
| Filter efficiency | > 99.9 % |
| Dust classification | M |
Basic data
| Max. extraction capacity | 164.8 cfm (280 m³/h) |
| Extraction performance at 126.5 cfm @ 72.3 in. (18000 Pa | 215 m³/h) |
| Max. fan performance | 164.8 cfm (280 m³/h) |
| Maximum vacuum | 128.5 in. (32000 Pa) |
| Dimensions (w x t x h) | 27 x 40 x 35 in (692 x 1018 x 878 mm) |
| Weight | 183 lbs (83 kg) |
| Motor power | 5.1 hp (3.8 kW) |
| Power supply | 3ph 460-480v (USA) 3ph 575-600v (Canada) / 60 Hz |
| Rated current | 8.1 A |
| Noise level | 73 dB(A) |
Additional information
| IFA-Certification | Certification submitted |
| Fan type | Slide channel blower |
| Compressed air supply | 87 – 116 psi (6 – 8 bar) |
| Hose connection | Ø2 x D = 1.77 / 2.48 in (Ø 2 x D = 45 / 63 mm) |
| Air outlet | 2.48 in (63 mm) |
