The basic mobile welding smoke extraction unit is designed for occasional use with low amounts of dust. The rotating and swiveling exhaust hood enables use in a 360-degree radius and ensures only few adjustments during welding. The basic device is suitable for welding high alloy steel due to its W3 approval.
| Filter Stage | 3 |
| Filter Method | Storage Filter |
| Filter Surface | 13 m² |
| Type of Filter | Filter Cassette |
| Filter Material | Non-woven Fibre |
| Filter Efficiency | > 99.5 % |
| Filter Class | E12 |
| Additional Filters | Two Pre-filters |
| Extraction Capacity | 950 m³/h |
| Dimensions (w x d x h) | 722 x 753 x 909 mm |
| Weight | 71 kg |
| Motor Power | 1.1 kW |
| Power Supply | 1 x 230 V / 50 Hz |
| Rated Current | 6.7 A |
| Control Voltage | 230 V, AC |
| Noise Level | 72 dB(A) |
| IFA-Certification | W3-Approved |
| Fan Type | Radial Fan |
| Quantity of Extraction Arms | 1 |
| Exhaust Arm Type | Flexible Exhaust Arm |
| Diameter of Extraction Arm | 150 mm |
| Length of Exhaust Arm | 2 m |
